| Interface |
• 5× 10/100/1000Mbps RJ45 Ports
• AUTO Negotiation
• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity |
Fanless |
| External Power Supply |
External Power Adapter (Output: 53.5 VDC / 1.31 A) |
| Packet Forwarding Rate |
7.44 Mpps |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4
• Power Supply: 65 W |
| Mac Address Table |
2K |
| Jumbo Frame |
16 KB |
| Switching Capacity |
10 Gbps |
| Dimensions ( W x D x H ) |
3.9×3.9×1.0 in (99.8×98×25 mm) |
| Max Power Consumption |
• 4.29 W (220/50 Hz. no PD connected)
• 74.24 W (220/50 Hz. with 65 W PD connected) |
| Max Heat Dissipation |
• 14.63 BTU/h (no PD connected)
• 253.16 BTU/h (with 65 W PD connected) |
