Chipset
|
AMD® B850
|
|
Chip
|
Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
|
|
Podrzana memorija
|
4x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 256GB (4x 64GB), up to 8000 MHz(OC)
|
|
PCI-E slotovi za nadogradnju
|
1x PCIe 5.0 x16, 1x PCIe 4.0 x4 in 16x slot, 1x PCIe 4.0 x2 in 16x slot
|
|
Video izlazi
|
DisplayPort x1, HDMI x1
|
|
Audio
|
Realtek® ALC897 HD Audio, 7.1 Channel
|
|
Mreža
|
Realtek® RTL8125BG 2.5 Gigabit EthernetM.2 WiFi 7 Module, Support 802.11 a/b/g/n/ac/ax/be, 2.4 GHz / 5GHz / 6GHz band, Bluetooth 5.4 Support
|
|
Priključci za USB
|
1x USB 3.2 Gen1 (1 x Type C), 1x USB 3.2 Gen1 (2 x Type A), 1x USB 2.0 (2 x Type A)
|
|
Priključci nazad
|
1 × DisplayPort, 1 × HDMI ™, 1 × RJ45 LAN, 2 × Wi Fi AntennaOne-click Flash BIOS Button, 4 × USB 2.0, 3 × USB 3.2 Gen2 Type A1 × USB 3.2 Gen2 Type C, 6 × Audio Jacks
|
|
M.2 slotovi
|
1x PCIe 5.0 M.2, 2x PCIe 4.0 M.2, 4x SATA
|
|
Dimenzije
|
ATX, 305x244mm
|
|
Debug LED
|
DRAM: Yellow, CPU: Red, GPU: White, Boot: Green
|
|
link ka stranici
|
https://www.sapphiretech.com/en/consumer/mb_nitro_b850a-wifi7#Specification
|
